PDF Product Catalog


Series

Download

SM Series

• Dimension: 3511-1054
• Inductance: 1-1000uH
• DC Resistance: 0.01-1Ω
• Rated Current: 0.05-3.2A

Download

SMRH1 Series

• Dimension: 72-127
• Inductance: 10-470uH
• DC Resistance: 0.008-100Ω
• Rated Current: 0.1-5.0A

Download

SMR Series

• Dimension: 63B-105B
• Inductacce: 3.3-470uH
• DC Resistance: 0.07-2.0Ω
• Rated Current: 0.3-2.0A

Download

SD Series

• Dimension: 0402-1306 (Metric Size)
• Inductance:1-1000uH
• DC Resistance: 0.05-30Ω
• Rated Current: 0.05-15.0A

Download

LQH Series

• Dimension: 1206-2220
• Inductance: 0.12-1000uH
• DC Resistance: 0.2-250Ω
• Rated Current: 0.02-5.0A

Download

NR Series

• Dimension: 2012-8040
• Inductance: 0.9 -100uH
• DC Resistance: 0.006-4.0Ω
• Rated Current: 0.22-13.0A

Download

SMRH2 Series

• Dimension: 2D11-8D43
• Inductance: 1-100uH
• DC Resistance: 0.02-10Ω
• Rated Current: 0.1-3.5A

Download

SHC Series

• Dimension: 0603-1265
• Inductance: 0.1-10uH
• DC Resistance: 0.75-11.0Ω
• Rated Current: 8-90A

Download

FWI Series

• Dimension: 0603-1008
• Inductance: 1.0-100uH
• DC Resistance: 0.75-11.0Ω
• Rated Current: 0.04-0.42A

Download

NL Series

• Dimension: 2520-453232
• Inductance: 0.01-1000uH
• DC Resistance: 0.13-40Ω
• Rated Current: 0.03-0.45A

Download

HWI Series

• Dimension: 0603-1210
• Inductance: 6.8-6800uH
• DC Resistance: 0.065-8.2Ω

Download

RI Series

• Dimension: 0304-1016
• Inductance: 1-8200uH
• DC Resitance: 0.05-50Ω
• Saturation Current: 0.02-5.0A

Download

T Series

• Dimension: T30-T130
• Inductance: 1.0-10000uH
• DC Resitance: 0.01-20Ω
• Rated Current: 0.01-20A

Download

CI Series

• Dimension: 1005-3216 (Metric size)
• Inductance: 0.047-100uH
• Q Value: 10-50
• SRF: 7-320MHz
• DC Resitance: 0.15-3.45Ω
• Rated Current: 0.001-0.3A

Download

CH Series

• Dimension: 0603-2012 (Metric size)
• Inductance: 0.001-0.47uH
• Q Value: 4-15
• SRF: 200-10000MHz
• DC Resitance: 0.10-3.5Ω
• Rated Current: 0.15-0.5A

Download

CMW Series

• Dimension: 2012-3216 (Metric Size)
• Impedance: 90-2200Ω
• DC Resistance: 0.3-1.2Ω
• Rated Current: 0.05-0.3A

Download

CB Series

• Dimension: 0603-4532 (Metric size)
• Impedance: 0-2500Ω
• DC Resitance: 0.05-1.6Ω
• Rated Current: 0.05-2A

Download

PB Series

• Dimension: 1608-4532 (Metric size)
• Impedance: 0-1000Ω
• DC Resitance: 0.005-0.4Ω
• Rated Current: 1-6A

Download

UU Series

• Inducrance: 0.5-30 mH
• DC Resitance: 0.2-8.0 Ω
• Rated Current: 100 – 2000 mA

Download

CBA Series

• Dimension: 1608-3216
• Impedance: 33-1000Ω
• Rated Current: 50-500mA

Download

RH Series

• Dimension: 2.5*3.0*10 - 3.5*9.0*0.8
• Impedance: 25-50Ω

Download

LF Series

• Dimension: 0204-0512
• Impedance: 0.1-10000uH
• DC Resitance: 0.08-105Ω
• Rated Current: 20-1400mA

Download

SMD Series

• Dimension: 5845-8050
• Harious package size and wide inductance range.
• Design as customer’s request specification.

Download
